Liquid Water filling and capping machine
Liquid Water filling and capping machine used for water, juice , soy milk ,yogurt and so on liquid material.
Product Introduction
Inflation bag filing sealing machine (bar milk bags machine, bar yogurt bags machine, it can auto filling and sealing in the airless condition)this machine is made of prefabricated
forming bag. no gas pressure filling is one of the packaging industry, liquid packaging is popular in the international packaging industry; It has novel packaging forms and various shapes,The sealing is firm and easy to use. It is widely used in dairy products, bean products (Japanese bean curd) condiment,washing products, juice drinks, alcohol and other fluids can be filled and sealed in airless state to avoid secondary pollution.
1. The machine adopts man-machine interface, PLC control system, intuitive and simple operation, low failure rate
2. The quantitative system is controlled by computer. The volume of liquid can be changed by directly controlling the number on the computer screen.Measurement, completely avoid the mechanical quantitative instability.
3. Intelligent temperature controller is used for sealing, which can control temperature accurately. Linear bearing is used for sealing pressure
The straight down type makes the pressure of the sealing die head more uniform and the product seal more firm. It completely adopts the rocker type adjustment
The state of unstable pressure and easy displacement.
4. The machine adopts 2 working positions and 8 filling heads. Besides manual bagging, filling, sealing and bagging are automatically completed.
| Model | HF2000 |
| The production efficiency | 800-2600 bags/hour |
| Air supply: | 0.3-0.5m/min 0. 8mpa |
| Measuring range | 50-500ml/bag |
| Voltage | 220V 50HZ |
| Power | 1.2-1.6KW |
| Machine weight | 180kg |
| Dimensions | 1200*700*1550mm |
